括苍天文是 ATIK CCD 中国区总代理 ,销售ATIK各种产品的销售和售后服务。
ATIK官方网站:[url=]http://www.atik-cameras.com/[/url]



ATIK4000LE Large-Format CCD Camera - Color Kodak KAI-04022 Sensor
  • TheAtik 4000LE Large-Format CCD Camerautilizes a 4 Megapixel Color Kodak KAI-04022 Sensor.
  • At 15mm x 15mm, the sensor array is a perfect fit for standard 1.25" filters, offering a considerable saving over the 2" filters.
  • Cooling is provided by a single-stage Peltier element, there is no water-cooling option, and fewer accessories are included..
  • Compatible with our highly acclaimed Capture software as well as Astroart, CCDSoft, and MaximDL.
  • TheAtik 4000LE Large-Format CCD Camerais a reduced cost version of the popular ATIK 4000 camera. It features the same sensor and electronics as the ATIK 4000.

[tr][/tr]

Atik 4000LE Large-Format CCD Camera - Color Kodak KAI-04022 SensorThe ATIK 4000LE is a reduced cost version of the popular ATIK 4000 camera. It features the same sensor and electronics as the ATIK 4000, but cooling is provided by a single-stage Peltier element, there is no water-cooling option, and fewer accessories are included. If you want the imaging power of the ATIK 4000 but don't need these extra features, then this is the camera for you.



While the other cameras in the ATIK range use Sony sensors, the Large-Format cameras incorporate Kodak devices. These have gained a great reputation in astrophotography and offer qualities not available in the Sony CCDs. However, optimum performance from the Kodak chips is only obtained with the use of highly sophisticated control electronics and advanced cooling systems, and this is where ATIK's expertise in design and build comes to the forefront.

The Kodak sensors require dark frames to be used for calibration, and these must be taken at the same temperature as the primary image. The ATIK 4000LE achieves this through the provision of full, set-point, temperature regulation using a single-stage Peltier element and fan. This can provide cooling to 33 degrees below ambient.

Such efficient cooling cuts thermal noise to an absolute minimum and reduces the prevalence of hot pixels, but it raises the risk of condensation forming in or on the camera. A high-efficiency desiccant is used to dry the air inside the sensor chamber, preventing internal condensation, while condensation on the outside of the camera is avoided with the use of heater elements which gently warm the window. The power supplied to this heater is controllable through software so that it can be adapted to the environmental conditions.

The ATIK Large-Format cameras have been designed and built to fulfil the needs of the most demanding users, while offering an unparalleled simplicity of use. The cameras have only two sockets - a 2.1mm socket for the 12V power supply and a USB2 port for communicating with the computer - and they are compatible with our highly acclaimed Capture software as well as Astroart, CCDSoft, and MaximDL.


Atik 4000LE Large-Format CCD Camera Features...
  • Camera body with 2” adapter
  • 3 meter USB cable
  • 1.8 meter battery power connector (with car lighter plug)
  • universal (110-230V) power adapter is included
  • CD-ROM with drivers, software and user manual (PDF)
  • Quick start guide (printed)
Our highly acclaimed Capture software is included for camera control and data acquisition, and plug-ins are included to allow use with Astroart , CCDSoft and MaximDL. System requirements: Pentium II PC with 64MB RAM, Windows 98/XP/Vista, CD-ROM drive and USB 2.0 port.


About the Kodak KAI-04022 Sensor...The Kodak KAI-0340D (Dual) image sensor is a 640 (H) x 480 (V) resolution, 1/3” optical format, progressive scan interline CCD. The KAI-0340-Dual will support 210 full resolution frame-per-second readout. Frame rates as high as 3,400 Hz can be achieved using the Fast Horizontal Line Dump feature to eliminate horizontal lines during readout and special clocking mode enabled by this sensor.





Designed for demanding imaging applications, this sensor has additional features including electronic shuttering, peak QE (quantum efficiency) of 55%, extremely low noise and low dark current. These features give this sensor exceptional sensitivity and make it ideal for a variety of imaging applications.


Kodak KAI-04022 Imaging Sensor Features
  • Maximum Frame Rates: 8 fps (single output) 16 fps (dual output) - Image Lag: <10 e - Smear: -80 dB - Blooming Suppression: 300X
  • Dark Current: < 0.5 nA/cm2 - Dark Current Doubling Temperature: 7oC
  • Charge Transfer Efficiency: > 0.99999 - Charge Capacity: 40,000 electrons - Number of Outputs: 1 or 2
  • Active Image Size: 15.15mm (H) x 15.15mm (V) 21.43mm (diagonal) - Aspect Ratio: 1:1
  • Peak Quantum Efficiency: 55% - Readout Noise (f=10MHz): 9 electrons, rms
  • Package Type: 34 pin CerDIP - Cover Glass: AR Coated, 2 side
Atik Product Number:A3-4000LE-C
